T2450 active electronic label

  • Introduction
  • Specification
  • Appearance
  1. Long reading distance, the longest reading distance can reach more than 200 meters (the reading distance is related to the application environment and antenna)
  2. Ultra-low power consumption, long service life
  3. Good anti-collision performance in the air, more than 500 tags can exist at the same time
  4. High IP protection level
  5. Large-capacity user area, which can meet different applications
  6. With intelligent temperature detection function
  7. With RSSI field strength detection function

Typical application

Electric vehicle management

Tag name T2450 active electronic label
frequency 2.4GHz~2.48GHz ISM
Induction method Active emission, once every 1.5 seconds (the emission time is adjustable)
Material ABS, black
Dimensions 56.25*34.5*11.6mm
Industrial grade IP67
Signal modulation method GFSK
Communication rate 1Mbit/s
Output power (maximum) 7dbm
quiescent current <3uA
peak current <25mA
Working current <20mA 3V
ID number 4 byte serial number
RSSI function Yes
Battery capacity 500mAh
Service life 3+ years (transmitted every 1.5 seconds and with a transmission power of 7dbm)
Working temperature -20℃~+45℃
Storage temperature -30℃~+65℃
Drop test 1.2 Drop test
