P6051 is equipped with Android 7.0 operating system, a 5-inch IPS high-definition screen with a resolution of up to 720*1280, and a quad-core 64-bit Coretex-A53. It is an intelligent industrial-grade handheld terminal that fully supports various IoT frequency bands and application functions.
P6051 can be widely used in various industries of the Internet of Things, such as: logistics and transportation industry, electric power industry, commodity traceability industry, sales management industry, warehouse management industry, commodity anti-counterfeiting industry, anti-counterfeiting anti-counterfeiting industry, asset management industry, inspection and patrol industry, etc. Wait. With the main goal of realizing the special needs of industry customers, relying on flexible and customizable modular combinations, it solves customers’ core problems and provides a solid foundation for customers’ mobile Internet of Things applications.
| Basic parameters | |
| Overall size | 170*85*23±2mm |
| Complete machine weight | 400 grams |
| Display | 5-inch IPS high-definition screen, resolution 720*1280 |
| touch screen | Corning Gorilla III industrial-grade multi-touch capacitive screen |
| Expansion Slot | 1 SIM card slot, 2 PSAM card slots and 1 MicroSD(TF) card slot |
| Communication interface | High-speed USB2.0 device port interface 3.5 hybrid charging port |
| Audio | Support voice broadcast |
| Indicator light | Network indicator, charging indicator |
| Keyboard | Scan key, function key |
| Camera | Rear 8 million pixel camera with flash and auto focus |
| Flashlight | Low power consumption LED lighting, emergency use |
| GPSNavigation | Built-in GPS global positioning system, the error range is ±5m |
| Performance parameters | |
| CPU | Quad-core 64-bit Coretex-A53 |
| Memory Capacity | RAM: 2GB ROM: 16GB |
| operating system | Android7.0 |
| Extended memory | Support 128GB MicroSD card |
| Data communication | |
| 4G | TD-LTEBand38/39/40/41FDD-LTEBand1,2,3,4,7,17,20 |
| 3G | WCDMA(850/1900/2100MHz); |
| 2G | GSM/GPRS/Edge (850/900/1800/1900MHz) |
| WIFI | 2.4G/5G dual-band, compliant with IEEE802.11a/b/g/n |
| Bluetooth | Compliant with Bluetooth4.0 |
| Barcode collection (optional) | |
| One-dimensional barcode | |
| One-dimensional laser scanning module | HoneywellN431X/Others |
| Support one-dimensional barcode type | Code39, Code93, Code128, Codebar, EAN-13, EAN-8, UPC-A, UPC-E, ITF14, UCC/EAN-128, ITF25, Matrix25, EAN -128, ISBN, etc. |
| 2D barcode | |
| 2D scanning engine | Honeywell-6603/Other |
| Support 2D barcode | PDF417,MicroPDF417,Composite,RSS,TLC-39,Data matrix,QR code,Micro QR code,Aztec,Maxi Code,Postal Codes,US Post Net,US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal, etc. |
| Ultra High Frequency(UHF)Indicators | |
| RFID | Working frequency: 840-960MHz (customized according to the required frequency band)
Support agreement: EPC C1 GEN2/ISO 18000-6C Output power: 5dBm-30dBm Recognition distance: 0-7 meters |
| Working environment | |
| Operating temperature | -20℃～50℃ |
| Storage temperature | -20℃～70℃ |
| relative humidity | 5%～95% non-condensing |
| Protection class | Host IP65 (only for the host, excluding the extended RFID back clip) |
| Battery Performance | |
| Battery Capacity | 8100mAh lithium polymer battery |
| Standby time | Turn off wireless communication and other functions, it can stand by for 360 hours |
| Charging time | less than 8 hours |
