B6018 is a high-performance adsorption UHF RFID reader product. It is designed to carry the ultra-high frequency F90A1 read-write module developed by our company. The performance is stable and reliable, and the reading distance can reach 3 meters. Embedded with a new generation of high-performance ARM-COTEXM3 processor, the product has powerful functions, and can be built in master-slave mode and automatic mode. It has great scalability and can meet more customer needs.
The B6018 charging interface adopts Micro-USB and Type-C dual interface design, which is convenient for customers to use in different scenarios. Bluetooth adopts 5.0 design, conforms to FCC, CE, RoHS standards, has wide coverage and high communication speed. The B6018 adopts a plastic shell, with a simple and beautiful appearance, small and light, strong and durable. The adsorption installation method is suitable for the rapid application requirements of different mobile phones.
| Name | Description |
| Power button | Short press (50-2000ms) button to start the device |
| Short press the button twice within 1s, the device will shut down | |
| Power Indicator | The green light is flashing, the device is in the charging module or low battery mode |
| The green light is constant, the device is in full charge or normal discharge mode | |
| Bluetooth light | The blue light is always on, indicating that the Bluetooth connection is successful |
| Read indicator light | The green light flashes, indicating that the tag data is read |
| Battery Indicator | From high to low, the colors of the indicator lights are: green, yellow, orange, red |
| USB interface | Max support 5V/2A fast charging function |
| USB virtual serial port, support configuration of device parameters through computer,
With desktop card issuer function |
| Serial number | Name | Parameters |
| 1 | Appearance Dimensions | 138*70*15mm |
| 2 | Design | Plastic shell design |
| 3 | Buzzer | Active buzzer, software configurable |
| 4 | Communication interface | Micro-USB Type-C |
| 5 | Antenna Type | Circular Polarization Ceramic Directional Antenna |
| 6 | Working temperature detection | Support |
| 7 | Interface communication speed | 115200bps |
| 8 | Writing distance | 0～1m (related to tag type, transmission power and application environment) |
| 9 | Reading distance | 0～3m (related to tag type, transmission power and application environment) |
| 10 | RF port standing wave | ≤1.5 |
| 11 | Receive Sensitivity | -62dBm |
| 12 | Output power flatness | ±0.2dBm |
| 13 | Output power | software adjustable, step interval 1.0dB, +20dBm～+30dBm |
| 14 | Support work area | China 1, China 2
US, Canada and other regions following U.S. FCC Europe and other regions following ETSI EN 302 208 with & without LBT regulations Japan Korea Malaysia Taiwan |
| 15 | Working frequency band | 840～960 MHz |
| 16 | Label Agreement | EPC global UHF Class 1 Gen 2 / ISO 18000-6C |
| 17 | Storage temperature | -30～+70℃ |
| 18 | Working humidity | ≤95%（+25℃） |
| 19 | Operating temperature | 0～+65℃ |
| 20 | Power supply method | Built-in polymer lithium battery, charged by USB interface |
| 21 | Battery Capacity | 2800mAh/3.7V |
| 22 | Working hours | 8 hours/balanced mode |
| 23 | Bluetooth module | Bluetooth 5.0, FCC, CE, RoHS compliant |
