The smart door lock is equipped with a self-developed door lock control system, including a computer terminal and a mobile phone terminal, which can remotely control the door lock, monitor the door lock status, and the door lock can automatically return the door opening record in real time, so that the door lock and system data can be transmitted wirelessly in real time , with a number of functions to improve safety, can prompt and alarm, and the functions can be customized according to needs. Using high-efficiency wireless connection technology, the chip is energy-saving and efficient. It has passed the high and low temperature tests of -20 degrees and 70 degrees below zero, and it is normal for 100,000 times of door opening and collision.
It can be widely used in multiple scenarios, such as commercial residential areas, public rental housing, rental houses, hotels, apartments, smart buildings, office buildings, factory dormitories, schools, etc., through smart device + Internet management, realize intelligent door lock management and reduce duplication Work, reduce management costs, improve work efficiency and service quality, and adapt to all door lock management needs.
| ProductsParameters | |
| Model | MW08 |
| panel color | Black |
| Material process | The lock surface is made of aluminum alloy and tempered glass, CNC technology, durable, strong anti-destructive. |
| Applicable door thickness | 38-70mm (special thickness needs to be customized) |
| Surface Craft | Anode oxidation process on the surface of the door lock, wear-resistant, strong anti-corrosion, longer service life |
| Free handle | Explosion-proof, anti-compression handle structure, durable |
| Handle material and color | Aluminum alloy material, panel same color |
| Battery cover material/color | ABS (black) |
| Sensor Cover Material/Color | Wear-resistant tempered glass, black bottom |
| Lock body | Adopt international standard lock body. Lock bolt and transmission parts are made of 304 stainless steel. |
| Mechanical key | It is equipped with a spare mechanical key to ensure that the door lock can be opened in an emergency, and it can be customized as a single open/through open |
| Motor | Adopt domestic special motor for door lock, reduce gear box driving structure with large torque, quick response, stable transmission and long service life |
| Power Consumption | ＜85UA (4 AAA alkaline batteries for 8-12 months), can be turned on normally for more than 15,000 times |
| quiescent current | <25 microamps |
| Dynamic Current | <150mA |
| Reading distance | 0～5cm |
| Read and write time | <0.1 seconds |
| Read and write mode | Contactless sensor |
| Opening hours | After swiping the card, press the handle to open the door once, and if the door is not opened, it will be automatically locked within 3-5 seconds |
| Unlock Record | Super-capacity memory chip can store the latest 900 unlocking records (including mechanical key unlocking records) |
| Operating temperature | -20℃～70℃ |
| Working Humidity | 15～95%RH |
| Storage Temperature | -25°C～70°C |
| Storage Humidity | 10～98%RH |
