P6045 is equipped with Android 5.1 operating system, equipped with a 4.0-inch industrial-grade capacitive touch screen with a resolution of (480*800), and a Qualcomm quad-core processor. It is an intelligent industrial-grade handheld terminal that fully supports various IoT frequency bands and application functions.
P6045 can be widely used in various industries of the Internet of Things, such as logistics and transportation industry, electric power industry, commodity traceability industry, sales management industry, warehouse management industry, commodity anti-counterfeiting industry, anti-counterfeiting anti-counterfeiting industry, asset management industry, inspection and patrol industry, etc. With the main goal of realizing the special needs of industry customers, relying on flexible and customizable modular combinations, it solves the core problems of customers and provides a solid foundation for customers’ mobile Internet of Things applications.
| Physical parameters | |
| Overall size | 213mm * 87mm * 151mm |
| Complete machine weight | 721 grams (UHF and dual battery system) |
| Display | 4 inches, (480*800) resolution, 16.7M colors, adjustable backlight brightness |
| Touchscreen | Industrial grade capacitive touch screen |
| Battery Capacity | The host is equipped with a rechargeable lithium polymer battery 3200mAh |
| The handle contains a rechargeable lithium battery 5200mAh | |
| Expansion Slot | Two PSAM card slots, one MicroSD(TF) card slot |
| Communication interface | Micro USB (support OTG) |
| Audio | Microphone, earpiece, 0.5W speaker, support voice calls |
| Keyboard | 4 TP buttons + 3 side buttons + QWERTY physical keyboard/number pad |
| Sensor | Light sensor, distance sensor |
| Performance parameters | |
| CPU(1) | Qualcomm 1GHz quad-core |
| RAM+ROM | 1GB+8GB |
| CPU(2) | Qualcomm 1.3GHz quad-core |
| RAM+ROM | 2GB+16GB |
| Extended memory | Micro SD (TF) card can be expanded to 128GB |
| Development environment | |
| Operating System | Android 5.1 |
| SDK | Xunyuan Software Development Kit |
| Development language | Java |
| Development Tools | Eclipse |
| Environment | |
| Operating temperature | -20℃-50℃ |
| Storage Temperature | -40℃-70℃ |
| Ambient humidity | 5%RH – 95%RH (non-condensing) |
| Drop Spec | In the operating temperature range, the 6 sides can withstand multiple times from a height of 1.2 meters |
| Impact of a drop to concrete | |
| Scroll Test | Consecutive rolling 1000 times 1.6 feet/0.5 meters, 6 contact surfaces still running stably after rolling, reaching IEC rolling specification |
| Protection class | The host IP64 meets IEC sealing standard
(Only for the main unit, not including the extended RFID back clip) |
| Data communication | |
| WLAN | Support IEEE802.11 a/b/g/n protocol, built-in antenna |
| WWAN | 2G: GPRS (850/900/1800 MHz)
3G: WCDMA-B1 CDMA EVDO: EVDOR RevA 800MHz TD-SCDMA: B34, B39 4G: TDD-LTE: B38, B39, B40, B41 FDD-LTE: B1, B3 |
| Bluetooth | Bluetooth 4.0 |
| GNSS | Integrated GPS, AGPS, built-in antenna |
| Data Collection | |
| Barcode collection (optional) | |
| One-dimensional scanning engine | Honeywell N4313/ Zebra SE965 |
| Support one-dimensional barcode type | UPC/EAN, Code128, Code39, Code93, Code11,
Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc. |
| 2D scanning engine | Zebra SE4500 |
| Support 2D barcode type | PDF417, MicroPDF417, Composite, RSS, TLC-39,
Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX) etc |
| RFIDUHF | |
| Working Frequency | 840-960MHz (customized according to the required frequency band) |
| Support Agreement | EPC C1 GEN2/ISO 18000-6C |
| Power | 5dBm-30dBm |
| Recognition distance | 0-10 meters (reading distance and group reading rate are related to the actual environment) |
