| Name | Specifications | Remarks |
| Frequency (MHZ) | 902-928 | |
| Gain (dBi) | 12 | |
| Horizontal plane lobe width (°) | 120 | |
| Vertical lobe width (°) | 30 | |
| Back to Front Ratio (dB) | ≥20 | |
| Bandwidth (MHZ) | 26 | |
| VSWRratio | ≤1.5 | |
| Polarization | Linear polarization | |
| Maximum power (W) | 100 | |
| Impedance (Ω) | 50 | |
| connector model | Block N | |
| Weight (kg) | 4.9 | |
| Dimensions (mm) | 600×150×80 | |
| Strut rod diameter (mm) | φ50～70 |
